Optics and light source
• 37 high power RGBW LED’s 30 W
  Standard RGBW-LED CRI > 80
  Optional RGBY-LED CRI > 90
• > 1,100 W LED power
• > 20,000 h LED life time
• Flicker free operation, camera mode up to 3 kHz
• TwinZoom zoom range: 4° to 70° (17:1)
  optional: zoom range 3° to 68° (22:1)
• High efficient optical system with perfect color mixing

Effects
• Individual LED control - single pixel control
• Sparkle-Effect for dynamic effects like a starlight effect
• Various layers of effects can be combined
• Countless pattern/color combinations
• Glow- and color spread-channel for additional color mixing options
• Separate CTC channel
• Optimized color mixing performance
• High-resolution, step less dimmer 0-100%
• Color true dimming
• Electronic strobe with pulse and random effects
• TwinZoom system zoom range 4°-70° (17:1)
  optional: zoom range 3° to 68° (22:1)
• Optional rotating beam shape

Movement
• High-resolution 3 phase stepping motors
• Precise, extreme fast and silent movement
• 540° Pan / 333° Tilt

Control and programming
• Protocol: USITT DMX-512, RDM
• Ethernet interface with Art-Net and sACN
• Wireless DMX / RDM / CRMX TiMo - Lumen Radio
• Bluetooth, WLAN
• Color touch display with function keys and battery backup
• Mini USB for software update
• Stand-alone mode
• Master/slave function, Built-in DMX analyser

Construction
• Rugged construction
• LEDs individually exchangeable without soldering
• Patented cooling system - super silent
• Fan control for virtually noiseless operation
• Graphical display, electronically rotatable
• Neutrik 5pin XLR IN / OUT
• Neutrik etherCON RJ45 IN/OUT
• Neutrik PowerCON TRUE1 IN / OUT

Rigging
• 2 omega brackets with original Camloc connectors for quick and comfortable mounting in any direction with four different mounting possibilities

Electrical specification
• Max. power consumption approx. 1300 VA
• Input voltage range 100 – 240 V, 50/60 HZ

Mechanical specifications
• Dimensions: W 470 x H 580 x D 310 mm
• Weight: 19,0 kg
