Column Diameter 152 mm
Maximum Lifting Capacity 2 450 daN / 1700 daN
Maximum Static Capacity 3 550 daN
Maximum travel 3.58 m
Maximum Speed up to 0.117 m/s *
Closed height for travel of
1.2 m 226 mm
3 m 424 mm
Lift Travel per Revolution (pitch) 32.8 mm
Drive Integrated Reducer with 2 Output Shafts
Total Ratios
(includes worm ratios), Rt 32.5, 16.25, 10.83, 8.17
Worm Gear Ratios, R 32.5, 16.25, 10.83, 8.17
Total System Lifting
Efficiency, EL up to 67 %
Column Material (bands) Stainless Steel 301
